| Item | HF200-3615 | |
| Specifications | 1*LAN + 1*RS232 + 2*Optical output + 1*RF input | |
| Optical Parameter | Wavelength（nm） | 1528～1563nm（ITU-T） |
| Optical output power | 10mw | |
| Connector type | FC/APC or SC/APC | |
| Optical Reflection Loss | >45.0dB | |
| Laser Type | ||
| Light modulationmode | ||
| RF parameters | RF Band | 47～860 /1000MHz |
| RF Input level | 75±3dBuV | |
| Level Difference of Narrow-Band port andMain Port | 8～20dB (Optional) | |
| Nominal RF Input Impedance | 75Ω | |
| RF Input Reflection Los | ≥16dB（47～550MHz） ≥14dB（550～1000MHz） | |
| Flatness | ≤±0.75dB | |
| Input Level Detection | 20dB±1dB | |
| Link Parameter | C/N | ≥50.0 dB |
| CSO | ≥48.0 dB | |
| CTB | ≥65.0 dB | |
| MER | ≥36 dB | |
| CNR | ||
| SBS Suppression | ||
| General Parameter | Power Supply | AC：100～240V |
| Power consumption | 30W | |
| Working Temperature | -5℃～45℃ | |
| Working relativeTemp | ||
| Storage Temperature | -25℃～+65℃ | |
| Size (Length x Width x Height) | 483mm×320mm×44mm | |
| Reference Net Weight | 4Kg | |
| Power loss |
| NO. | Product Model | Specifications | Accessories |
| 1 | HF200-3615 | 1*LAN + 1*RS232 + 2*Optical output + 1*RF input | |
| 2 | HF200-3615E | 1*RJ45 + 1*RS232 + 2*Optical output + 1*RF input |
